[氟塑料纜] 問下大家UL1332 28AWG的線OD都做多大？

P:2012-05-21 09:48:05

1

問下大家UL1332 28AWG的線OD都做多大？

third-circuit crosstalk - 第三回路串音 （0） 投訴

P:2012-05-21 11:26:21

2

<div id="OldPanel" style="WIDTH: 100%">
APPLIANCE WIRING MATERIAL
Subj.758Section 1Page 1332Issued:1963-02-04
Revised:2008-05-27
Style 1332Insulated Wire.

Rating200 deg C, 300 Vac, Horizontal flame, Oil Resistant 80 deg C (optional), Gasoline Resistant (opt)
Conductor30 AWG - 10 AWG solid or stranded round.
InsulationFEP, 13 mils min average, 12 mils minimum at any point.
Covering(Optional) FEP, 2 mils or heavier or glass braid 7 mils or heavier.
StandardAppliance Wiring Material UL 758.
MarkingGeneral.
UseInternal wiring of appliances. In addition, the tag may also indicate the following: Suitable for immersion in gasoline; gasoline vapor; 80 deg. C in oil; and or 600 volts peak for electronic use only.

UL and the UL Logo are trademarks of UL LLC © 2012 </div>
